Mobile Intelligent Unmanned Forklift

AGV system

Mobile Intelligent Unmanned Forklift

MF20T is a transportation-type intelligent unmanned forklift suitable for point-to-point transportation on flat roads.  With a rated load of 2000kg, it is suitable for medium and long-distance transportation tasks between standard pallets, leg-type boxes, non-standard material trucks/shelves/tooling, etc. Supports automatic cross-floor transportation of goods on and off elevators.

    Mobile Intelligent Unmanned Forklift-044ek

    Function

    Autonomous positioning and navigation: using laser SLAM and other technologies to achieve precise positioning
    Flexible motion control: using steering wheel drive to support forward, backward, left and right steering, rotation and other motion controls
    Intelligent power management: supports multi-level battery threshold control, automatically charges when the battery is low, and automatically resumes work after charging is completed.
    Multiple safety protections: front and rear laser obstacle avoidance, warning contour lights, three-sided collision detection, emergency stop button and other multi-level safety protections.
    Human-computer interaction friendly: supports touch screen, voice, light alarm to indicate device status
    Large cargo handling: supports the transportation of 2,000 kilograms of cargo.
    Cross-floor transportation: supports docking elevators to transport goods, and automatically transports goods across floors by going up and down elevators.
    Wireless network communication: Supports WIFI and 5G network communication, seamless roaming, and can barrier-free operation in the network coverage area.

    Application

    Machinery manufacturing, automobiles and parts, new energy, 3C, tobacco, pharmaceutical and other workshop environments, involving the transportation of raw materials, parts, and finished products on pallets, containers, and crates.

    Series Products

      Standard:●      Option :○ Mobile Intelligent Unmanned Forklift-02248
    Model MF20T
    Basic parameter Rated load(kg) 2000
    Controller Kecong
    Navigation mode Laser
    Dimension(L*W*H mm) 1871*941*2180
    Load center distance(mm) 600
    Maximum lifting height(mm) 120
    Fork size(l/e/s)(mm) 1150/175/55
    Fork height from the ground(mm) 86
    Fork inside/outside width(mm) 290/680(customizable)
    Safety protection Laser obstacle avoidance
    Sound alarm
    Bumper
    Emergency Stop Button
    Fork tip collision detection
    Warning Contour Light
    Optional Feature Dashcam
    Pallet Recognition
    3D obstacle avoidance
    Driving Performance Rated Travel Speed(m/s) 1.5
    Lifting Speed Loaded/Unloaded(mm/s) 40/43
    Lowering Speed Loaded/Unloaded(mm/s) 45/35
    Gradeability Loaded/Unloaded(%) 5/5
    Docking Accuracy ±10/±1
    Minimum Turning Radius(mm)/ (°) 1730
    Aisle Width(mm) 2684
    Battery performance Rated operating time(h) 6~8
     Charge time after full discharge(h) ≤1.5
